Description

“TPMS B-11” is a system that detects the air pressure inside the tire using a transmitter sensor attached to the wheel and notifies the driver through the in-vehicle monitor (receiver). By monitoring tire air pressure and warning of low air pressure, it is possible to ensure safety and security while driving. This product also contributes to environmental conservation.

The TPMS B-11 consists of a sensor transmitter attached to the wheel and a monitor (receiver) attached to the dashboard and is powered by the vehicle accessory power supply. The sensor transmitter detects the air pressure in the tire and transmits the data to the receiver by radio wave. It is designed to inform the driver of the air pressure status with three red, yellow, and green lamps, green when all four tires are normal, and yellow (caution) or yellow when the air pressure of one of the four tires is low. The red (error) lamp lights up.

Transmitter details
Install a TPMS sensor transmitter in place of the tire valve on each tire. The sensor transmitter is equipped with an acceleration sensor, which measures the air pressure inside the tire when driving at approximately 40km/h or more or when the pressure suddenly drops and transmits the data wirelessly to the receiver.

Receiver details
The built-in receiving antenna receives tire pressure data from the sensor transmitter and informs the driver of the information with an LED display. Connect the connector to the vehicle accessory power supply and the back of the receiver with the supplied power cord.
