Description

The ENDLESS Racing MONO block series, which is equipped with a pipe guard and has further increased rigidity from Racing MONO
6, has been developed by thoroughly pursuing rigidity by forging and integral molding. The newly released “Racing MONO6 Rally & Racing MONO4 Rally” uses the latest CAE technology and uses new materials to succeed in increasing the rigidity at higher temperatures.
Compared to the conventional Racing MONO block series, Racing MONO6 Rally has 110% higher rigidity, and Racing MONO 4 Rally has 106% higher rigidity. Furthermore, by designing to guard the brake pipe, damage to the pipe due to flying stones during hard driving is prevented.

Compatible model
TOYOTA Toyota
GR Yaris
* The kit attached to the rotor can be installed on vehicles equipped with RC-grade 17-inch wheels.
GXPA16
Genuine rotor (outer diameter x thickness)
FΦ356 x 28 RΦ297 x 18

Specifications
Product name: System inch up kit / system inch up kit (rear only)
Manufacturer part number: FACX GXPA16
Rotor: 370 x 34/332 x 30 2PCS / 3PCS
Pad: RCP121 / RCP197

Delivery Leadtime
Back-order, made-to-order production about 2 months ~
ENDLESS BRAKE CALIPER

Selectable brake pads
The caliper dedicated brake pads use a method in which the material is selected so that customers can select the brake pads that suit their driving stage.

RacingMONO6_Rally dedicated brake pad material list
TYPE-R / MX72 / MX72_PLUS / CC35_type-E (+23,000 yen) / W003 (+15,000 yen)
RacingMONO4r_Rally dedicated brake pad material list
TYPE-R / MX72 / MX72_PLUS / CC35_type-E (+23,000 yen) ) / W003 (+15,000 yen)

About caliper order color
The ENDLESS forged caliper can be changed to a custom color except for some caliper bodies. Currently, available custom colors are mainly “anodized” and “high heat resistant paint”. Please choose from the colors listed below.

* The colors shown may differ from the actual colors depending on your display.
* The caliper shape does not change depending on the custom color.
The caliper custom color is 22,000 yen including tax (main unit price 20,000 yen) for each side of the caliper body.
* Racing MONO block series and MONO6 Sports cannot change the aluminate color due to the characteristics of the product.
[Notes on caliper order color]
◆The aluminate treatment is easily affected by continuous high-temperature conditions such as driving on a circuit, ultraviolet rays, etc., and may fade. Racing aluminate is recommended for those who want to suppress fading as much as possible.
◆The ENDLESS forged caliper uses a material with a high silicon content for high rigidity. Therefore, due to the characteristics of aluminate, some color unevenness may occur. Also, in the case of front and backset, the color tone may be different before and after. note that.
◆The RacingMONO series is treated with uncolored carbide aluminate (coloring is not possible due to the characteristics of the materials used).
◆For caliper kits with standard floating characters, the engraved character “ENDLESS” logo used for monoblock calipers can be applied upon request (see “Caliper kit custom processing additional charge list” below. ).
◆The brake pads included in the caliper kit can be selected. The brake pads that can be selected differ for each caliper. Brake pads other than the setting will be charged separately.
◆Regarding aluminate, re-anodizing at the time of overhaul cannot be performed. You will be asked to choose the paint.

About bell housing order color
The standard color of the brake rotor “Racing” and the caliper kit 2-piece type / 3-piece type bell housing is a blue aluminate finish except for some products. (* 1)
Special colors can be ordered upon request. (If you are concerned about fading, we recommend the custom color “Tough Ram Coat”.) Please choose from the colors listed below.

※1For the Racing MONO series, the tough ram coat is the standard-setting.
※The colors shown may differ from the actual colors depending on your display.
The price of the tough ram coat is 33,000 yen including tax (main unit price 30,000 yen) for each of the left and right brake rotors.
Other aluminate colors are 11,000 yen including tax (main unit price 10,000 yen) for the left and right brake rotors.

※Due to the characteristics of the product, the racing MONO block series and MONO6 Sports cannot be changed in aluminate color.
