Name: FUJITSUBO VVV Muffler for GR Yaris
Availability: InStock

FUJITSUBO VVV Muffler for GR Yaris

Product Code：470-21232

Please select per-product shipping when placing the order. This can be shipped via economy air shipping to most parts of Asia, the US, and Europe. However, the territories cannot be covered
with this shipping, we may request an additional shipping charge after the buyer place the order.
4.5% deduction when paying via Bank/WISE Payment

Description

Sports muffler with sound and power control function that can be operated in the car

Basic information

Product nameProduct Name	VVV (pre-certified product)
Part number item Number	470-21232
Authentication acquisition display authorized Number	JQR20212001 G16Et
JAN CODE	4944997423328
Compatible models application	GXPA16 GR Yaris 1.6 Turbo 4WD Body model: 4BA-GXPA16 Engine model: G16E-GTS Year: R2.9 ~ (2020.9 ~)
RemarksSpecial Note	・ Common to vehicles equipped with GR rear bumper spoiler (MS343-52008) ・ Cannot be installed on standard bumper vehicles. It is necessary to install the separately sold muffler garnish (070-21232) or the GR rear bumper spoiler. ・ For MT cars only ・ W tail (deformed) left and right out* This product is sold separately as a muffler. (Muffler garnish is sold separately.) * Proximity exhaust noise is measured at 4200 rpm because the specified rotation speed is not reached. * Genuine rear bumper notch cut required
remarksRemarks	・ The grade of the prototype vehicle is 1st Edition RZ ・ Our output is the data when the valve is fully open ・ Our volume is the data when the valve is fully open. The values in parentheses are the data when the valve is fully closed. When the valve is fully closed, only the left side is exhausted.

specification

modelType	Stainless steel + carbon model
outlet shapeTailtip Style	φ76 / φ92 round slash (carbon W / RL) * With tail length adjustment mechanism
Pipe diameterPipe Diameter	φ70.0-60.5
Accessory list fitting Parts	• 080-36601 Ring Gasket x 1 • 080-37601 Plate Gasket x 1 • M10 x 20mm Flange Bolt x 2 • M10 Flange Nut x 2 • Valve Control Unit x 1 • Dedicated Carbon Tail Pipe Set x 4
Option (paid)Additional Parts	Muffler garnish GXPA16 GR Yaris

Numerical value

	Standard (STD)	FUJITSUBO
Intermediate acceleration (50km/h→100km/h・3 speed)Acceleration	2.2 seconds	2.2 seconds
Maximum output peak Power	209.6kw(285.1ps)/5840rpm	216.8kw(294.8ps)/5820rpm
Maximum torque peaks Torque	402.8N･m(41.1kg･m)/4400rpm	408.7N･m(41.7kg･m)/4330rpm
Muffler weight weight	-kg	17.3кг
Volume idlingIdling Exhaust Noise	59dB	69(67)dB
Proximity exhaust noise (4875 rpm)Proximity Exhaust Noise	77dB	90(85)dB
2000rpmExhaust Noise	70dB	84(79)dB
4000rpmExhaust Noise	75dB	83(80)dB
1000rpm〜3000rpmExhaust Noise	80dB	90(87)dB

Ground height

Measurement vehicle	GXPA16 GR Yaris 1.6 Turbo 4WD (1st Edition RZ)
Roof height	1415mm (1450mm for vehicle lint certificate)
Measurement site	Intermediate pipe (on the rear axle)
minimum ground height	104mm
