Description

UNLOCK A MORE ENGAGING AND PERSONALIZED DRIVING EXPERIENCE IN YOUR GR SUPRA 3.0L.

The Blitz ZZ-R Coilover Set is specifically engineered for the Toyota GR Supra (DB02) with the B58 3.0L engine.

Featuring a tuned rear-biased spring rate and comprehensive adjustability, including front camber plates, it offers a significant lowering range. As a result, it transforms the Supra’s grand touring demeanor into a sharper, more agile, and visually commanding sports car.

Product Highlights

MODEL-SPECIFIC TUNING FOR THE GR SUPRA 3.0L (B58): Developed with spring rates (6.0kg/mm front, 8.0kg/mm rear) tailored to the performance and weight characteristics of the inline-six Supra. This rear-biased setup enhances rotation, sharpens turn-in, and improves overall chassis balance for a more responsive and engaging drive.

ADJUSTABLE FRONT CAMBER PLATES FOR PRECISION ALIGNMENT: The front struts are equipped with adjustable pillow ball upper mounts. This critical feature allows for precise negative camber adjustment, optimizing front tire contact during cornering to maximize grip and improve steering feedback. It also ensures even tire wear during spirited or track driving.

FULL CONTROL OVER HEIGHT AND DAMPING: Offers extensive adjustability to tailor the vehicle to your preferences. Provides a substantial lowering range (up to -55mm front, -50mm rear) for an aggressive stance and improved center of gravity. Also, it features 16-level damping adjustment front and rear to fine-tune ride comfort and handling sharpness.

OPTIONAL ELECTRONIC CANCELLER FOR SEAMLESS INTEGRATION: For vehicles that trigger a suspension warning light, Blitz offers an exclusive optional canceller (Part# 15218). This allows for a clean, fault-free installation by deactivating the vehicle’s chassis monitoring system, ensuring a professional result.

Technical Specifications & Application

This is a coilover suspension kit for the Toyota GR Supra (DB02) with the B58 3.0L engine (2020+).

Key Details:

• Product Name: BLITZ ZZ-R COILOVER SUSPENSION SET

• Key Benefit: Enhances the GR Supra 3.0L’s agility, stance, and driver engagement with tuned spring rates, full adjustability, front camber plates, and a wide lowering range.

• Application: Toyota GR Supra (DB02) with B58 3.0L engine (2020+).

• Spring Rates: 6.0 kg/mm (Front – BS Spring), 8.0 kg/mm (Rear).

• Adjustability: 16-level damping adjustment (front & rear). Height adjustable (F: up to -55mm, R: -5 to -50mm). Front adjustable pillow ball mount.

• Important Note: Rear damping dial is inside the wheel well. Pillow upper mounts may transmit more operational sound. Optional electronic canceller (15218) available separately to disable dashboard warning lights.
