JAOS BATTLEZ Lift-Up Set for VFCA Land Cruiser 250

JAOS BATTLEZ LIFT-UP SET FOR VFCA LAND CRUISER 250 2024~

Part Number: Gsoline:A733068A / Diesel:A733068B

This can be shipped via economy air shipping to most parts of Asia, the US, and Europe. However, since this shipping cannot cover all territories, we may request an additional shipping charge after the buyer places the order.

Description

This lift-up suspension kit combines titanium-blended coil springs with guaranteed sag resistance and high-performance dampers with adjustable damping force using a Harmoflex mechanism. It also features front vehicle height adjustment.

Product contents	Front coil springs, rear coil springs, height-adjustable front dampers, rear dampers, height adjustment wrench
vehicle height	Lift-up:　Front 20-50mm, Rear 25-30mm
Spring	Wire diameter Front 17.0 Φ Rear 17.0 Φ　 Spring rate: Front 75.0N/mm Rear 38.2N/mm Color: Silver
Shock absorber	Type Front: Low-pressure gas twin-tube dampers, ride height adjustable, Harmoflex® system Rear: Low-pressure gas twin-tube dampers, Harmoflex® system Damping force adjustment: 14-step dial adjustment Damping force Front: Rebound -20% to 9% increase, compression -9% to 22% increase (0.3m/sec/compared to stock) Rear: Rebound -35% to -8% increase, compression -20% to 7% increase (0.3m/sec/compared to stock) Stroke Front: +11mm, Rear: +22mm Body Diameter Front: Φ54, Rear: Φ54 Piston Diameter Front: Φ30, Rear: Φ30 Color Gray metallic
Installation method	Genuine replacement (uses genuine front upper mount)
Reference installation time	2.5-3.0 hours
Notes and supplementary explanations	The vehicle height adjustment function is only available for the front Sag guarantee included (coil springs only) GX grade: Compatibility not confirmed Vehicle manufacturers’ safety equipment, such as driver assistance systems and collision avoidance systems, may misrecognize or malfunction radar, cameras, sensors, etc., when the vehicle height is changed. *Please note that we cannot be held responsible for any malfunctions of these systems caused by changes in vehicle height due to the installation of our lift-up (or lowering) suspension, or for any accidents caused by such malfunctions.
Installation instructions	BATTLEZ Lift-Up Set for VFCA Land Cruiser 250 Series (A73#068#)

Product weight (weight of product alone excluding packaging) 41.42 kg
Packing size and weight
Packaging ① Height (H): 525 mm x Width (W): 400 mm x Depth (D): 420 mm Weight: 29.52 kg
Packaging ② Height (H): 250 mm x Width (W): 295 mm x Depth (D): 770 mm Weight: 15.75 kg
Total weight (total weight of all packages, including packaging) 45.27 kg
