Description

JAOS Front Bumper Guard Painted Matte Black – 117,800 yen / [Unpainted] – 102,400 yen
Taking advantage of the powerful genuine front grille design, we finished it in a style that creates an overwhelming presence even in a simple design. In addition, the four LED lamps embedded in the main body give an accent to the front face and create a higher-grade feeling.

Product details Front bumper guard body, square LED lamps (4 pieces), wiring set, JAOS emblem, high boss skull sticker
specification Body: ABS (Painted product: Matte black + Silver metallic)

Mounting method Bolt-on
Installation time 2.5-3.0 hours
Dimensions when mounted Overall length: + 38mm

GR SPORT, VX, AX, and GX cannot be installed.
* The lamps used in this product are vehicle inspection-compliant products that meet the standards for “other lights”.

Unpainted product is available / Product number: B016051NP

JAOS Fender Garnish type-X Painted Matte Black – 135,400 yen / [Unpainted] – 113,400 yen
Although it is a tight size of less than 10 mm on one side, it has a strong presence due to its precise design, and at the same time, the original dummy bolt creates a wild side view.

Product details Fender garnish body (8 pieces), dummy bolt (32 pieces)
specification Body: ABS (painted product: matte black/grained paint)
Dummy bolt: ABS, chrome plating

Mounting method Processing required
Installation time 2.5 hours
Dimensions when mounted Overall width: less than + 20 mm

A genuine mudguard can be installed.
JAOS Mudguard III can be installed (removal of the genuine mudguard is required).
* “JAOS Mudguard vehicle-specific mounting kit” scheduled to be released in March 2022.
GR SPORT, VX, AX, and GX cannot be installed.
Cannot be installed on vehicles with model list aero parts.

Drilling is required inside the front fender liner and rear bumper (1 place each).

Dummy bolts are available in “black” as an option.
Part Number: D134102 Price: 4,000 yen / 32 pieces * 32 pieces are required to install one unit

Unpainted product is available / Part number: B135051NP (for ZX)

JAOS Rear Pats Painted Matte black – 69,500 yen
With its simple, compact volume and sharp design, it tightens the rearview and at the same time emphasizes its sportiness. Furthermore, by installing the “JAOS Front Bumper Guard” as a set, which realizes a higher-grade styling, gives a sense of unity to the overall form.

Product content: Rear spats body left and right, bracket left and right, bolt set
specification
Body: ABS (painted product: matte black/textured)
Bracket: ABS (unpainted product)

Drilling is required in the rear bumper (one each on the left and right).
It is necessary to remove the genuine mudguard.
Brackets are not required when installing them together with JAOS Mudguard.

The attached end molding color is “black”. “Gray” is available as an option.
Part number: G996002 List price: ¥600 / 1.0m * 1.5m is required to install one unit

Unpainted product available / Part number: B028051NP (for ZX)

FLAT RACK SET 1250X1400 ROOF RAIL TYPE-A (4 LEGS) – 138,700 yen
The main body is made of lightweight and strong extruded aluminum and has toughness specifications that assume hard use while suppressing the increase in vehicle weight. By installing an option in the T slot provided on the floor bar, you can arrange it according to your needs and expand it to your favorite style. It is a high-quality roof rack that is particularly “MADE IN JAPAN” with various functionality and reliability.

Product details Body (floor bar x 6), foot set x 4, emblem sticker x 1
■ Body
material: Aluminum
color: Black aluminate
Size: W1250mm x L1400mm (Thickness: Corner cap 39mm, Aluminum frame 32mm)
■ Emblem sticker
material: PVC material (high boscal)
Size: 85mm x 18mm

Mounting method Bolt-on
Installation time 2.0-2.5 hours
Dimensions when mounted Overall height: +80-85mm

DOOR HANDLE PROTECTOR LC300 – 8,400 yen
A door handle protector that prevents scratches and dirt on the door handle that may be inadvertently attached when the door is opened or closed. The special design is cut according to the shape (dent) of the door handle of the car model, and the carbon-like design dresses up the door handle as sporty. Since it adheres to a strong adhesive surface, it can be firmly attached without being easily peeled off.

Product details 4 for the door handle
specification Carbon-like PVC material

BATTLEZ 2TAIL-PIPE EXHAUST (ZS-2) LC300 21+ F33A / 3.3L – 100,000 yen
High-quality full stainless-steel muffler with two oval tails on each side. Engraved with the BATTLEZ logo that enhances the sports mind. You can enjoy the crisp sound and the light bubbling that is typical of a sports muffler. With a certification plate issued by a certification body that has cleared the new noise regulations, you can use it with confidence without worrying about vehicle inspections.

Product details: Rear piece, nut, muffler ring
specification Rear piece: Stainless steel, Φ70
Tail: Stainless steel, Oval (115 x 61) x 2
BATTLEZ logo engraved 2010
Noise regulation-compliant plate
Proximity exhaust noise 78dB Acceleration running noise 82dB
Performance etc. Confirmed Display content: JQR10221012

Vehicles equipped with the “MODELLISTA Rear Styling Kit (Rear Skirt + Muffler Cutter)” cannot be installed at the same time.
* Can be installed if the muffler cutter is removed.

BATTLEZ muffler ZS for diesel vehicles Land Cruiser 300 series ZX – 85,000 yen
The muffler body is made of high-quality full stainless steel, and the circle-shaped bullet-shaped tail creates a powerful rear view. The tail part is laser-marked with the BATTLEZ logo to enhance the dress-up effect. You can enjoy the subdued and crisp sound typical of a sports muffler and the light revving. Comes with a certification plate issued by a certified organization that has cleared the new noise regulations, so you can use it with confidence without worrying about vehicle inspections.

Product details: Rear piece, nut, muffler ring
specification Rear piece: Rear piece: Stainless steel, Φ70
Tail: Stainless steel, circle type (Φ101)
BATTLEZ logo engraved
Comes with a 2010 noise regulation compliance plate
Proximity exhaust noise 79 dB Acceleration running noise 78 dB
Confirmed performance, etc. Display contents: JQR10231105

Genuine replacement

JAOS Mudguard Vehicle Specific Mounting Kit for Land Cruiser 300 Series [4 Mudguards] – 38,000 yen
It is a kit to facilitate the installation of a JAOS mudguard general-purpose type. The parts required for installation are set exclusively for the vehicle model. It also comes with a paper pattern that allows you to accurately cut the general-purpose mudguard body.

Product content Bolt set, pattern paper for 1 unit

Drilling of the rear fender and rear fender liner is required.
The Mudguard body is not included.
2 sets of “JAOS Mudguard III General-Purpose L Size” are required separately to install one car (front and back).
Bolts, washers, and nuts use some of the accessories of “JAOS Mudguard III General Purpose L Size” in addition to the accessories of this product.
Cut the “JAOS Mudguard III General Purpose L Size” using the pattern included in this product and attach it to the vehicle using the included bolts, washers, and nuts.

*Cannot be used with genuine mudguards.
*Vehicle with Modellista aero parts Not confirmed to be installed.

JAOS skid plate type-R Land Cruiser 300 series ZX – 51,800 yen
This is a skid plate based on the experience gained from participating in overseas rallies and off-road races. Made of aluminum with a 4mm thick body that combines high strength and lightness, it has a tough design that firmly protects the front bottom. Furthermore, the light gray powder coating applied to the surface forms a strong coating that can withstand harsh environments, providing strong protection for the main unit. Although it is an inconspicuous item due to the underparts, it is a professional spec model of the “JAOS Skid Plate” series that we recommend to users who can “understand the difference.”

Product contents:  Skid plate, bracket, bolt set, JAOS logo potting emblem
specification:
・Body: Aluminum 4.0mm (5052A)/Light gray powder coating
・Bracket: Stainless steel 4.0mm/Cationic electrodeposition

JAOS Transfer Guard Land Cruiser 300 Series ZX – 29,800 yen
This is a functional part that protects the transfer, which is prone to hits when driving off-road. The main body is made of stainless steel with a thickness of 2.5 mm and is a plate type that easily skids against obstacles. Furthermore, the tough surface is shot blasted and electrolytically polished, making it resistant to scratches and can be used with confidence for a long time.

Product contents: Transfer guard body
specification:
・Stainless steel 2.5mm/shot processing, electrolytic polishing

BATTLEZ Lateral Rod Rear Land Cruiser 300 Series ZX – 48,800 yen
Returns the rear hose to its proper value, which shifts from side to side due to raising and lowering the vehicle height. A special disk spring is used for the adjustment part washer to prevent it from digging in in the opposite direction.

Product contents: rear lateral rod
specification:
Steel, silver painted, turnbuckle adjustable Adjustment
range: Normal ratio -10 to 40mm Vehicle height ±100mm
Genuine replacement

BATTLEZ Lift Up Spring Ti-W ZX for Gasoline Vehicles Land Cruiser 300 Series ZX – 87,800 yen
The approximately 35mm lift gives the Land Cruiser an even more impressive silhouette. A lift-up spring that takes advantage of the “soft but firm” characteristics unique to titanium compound materials. We provide a warranty for long-term use with peace of mind.

Product contents: Front coil spring, rear coil spring
Vehicle Height: Lift up front: 35-40mm, rear: 35-40mm
Wire diameter: Front 17.5Φ Rear 17.5Φ
spring rate Front: 75.0N/mm Rear: 41.2N/mm (right), 38.8N/mm (left)
Color : Silver
Genuine replacement

BATTLEZ Lift Up Spring Ti-W for Diesel Vehicles Land Cruiser 300 Series ZX – 87,800 yen
The approximately 40mm lift gives the Land Cruiser an even more impressive silhouette. A lift-up spring that takes advantage of the “soft but firm” characteristics unique to titanium compound materials. We provide a warranty for long-term use with peace of mind.

Product contents: Front coil spring, rear coil spring
Vehicle Height: Lift up front: 40-45mm, rear: 40-45mm
Wire diameter: Front 17.5Φ Rear 17.5Φ
spring rate Front: Front: 80.0N/mm Rear: 41.2N/mm (right), 38.8N/mm (left)
Color: Silver
Genuine replacement

BATTLEZ Lowdown Spring Ti-W ZX Gasoline Vehicle Land Cruiser 300 Series ZX – 82,800 yen
A low-down spring that takes advantage of the “soft but firm” properties of titanium compound materials to achieve a setting that slows roll speed. It combines natural cornering, high stability, and a comfortable ride with little vibration. We provide a warranty for long-term use with peace of mind.

Product contents: Front coil spring, rear coil spring
Vehicle Height: Lowdown Front: -25~30mm, Rear: -35~40mm
Wire diameter: Front 15.5Φ Rear 15.5Φ
spring rate Front: Front: 72.5N/mm, Rear: 43.0N/mm (right), 40.0N/mm (left)
Color: Silver
Genuine replacement

BATTLEZ Lowdown Spring Ti-W for Diesel Vehicles Land Cruiser 300 Series ZX – 82,800 yen
A low-down spring that takes advantage of the “soft but firm” properties of titanium compound materials to achieve a setting that slows roll speed. It combines natural cornering, high stability, and a comfortable ride with little vibration. We provide a warranty for long-term use with peace of mind.

Product contents: Front coil spring, rear coil spring
Vehicle Height: Lowdown Front: -30~35mm, Rear: -30~35mm
Wire diameter: Front 16Φ Rear 15.5Φ
spring rate Front: Front: 77.5N/mm, Rear: 43.0N/mm (right), 40.0N/mm (left)
Color: Silver
Genuine replacement

JAOS side decal black  – 20,800 yen
A decal with simple straight lines that casually dresses up the side view. This product is cut to fit the vehicle and has a total length of 2.2m, making it compatible with long bodies.

Product contents: Set of 2 left and right
Material: PVC material
Size: W2,200mm x H75mm
Color: Black

JAOS Wheels
Check here for details & prices.
