Tein FS2 Suspension Kit for Tesla/GR86/BRZ/GR Yaris
¥206,800Original price was: ¥206,800.¥190,000Current price is: ¥190,000.
Product Code: VSGP2-N1AA3
Available only for TESLA. Under development for GR86/BRZ/GR Yaris
This can be shipped via economy air shipping to most parts of Asia, the US, and Europe. However, the territories cannot be covered with this shipping, we may request an additional shipping charge after the buyer place the order.
You can also purchase other TEIN parts from Easy Cars Japan. If you cannot find it in our catalog, drop us a message.
Spring included:
YesEDFC compatible: YesDamping
force adjustment (F/R): â—‹/â—‹
Overall length adjustment (F/R): -/-
Mount (F/R): Reinforced rubber mount included/Reinforced rubber mount included standard
vehicle height compared to OEM mm (F/R): -35/-35Vehicle
height adjustment range compared to OEM mm (F/R)Maximum (lower limit – upper limit): -95 to -15/-67 to -19Vehicle
height adjustment range compared to OEM mm (F/R)Recommended (lower limit – upper limit): -40 to -20/-45 to -25Spring
rate Kgf/mm (F/R): 11.0/12.0Free
length mm (F/R): 215/240Inner
diameter mm (F/R): -/-
remarks
Rear: Interior needs to be cut or removed.
Rear: Due to the structure of the vehicle, manual damping force adjustment is difficult, so simultaneous installation of EDFC is recommended.
Values ​​are calculated based on stock vehicle height.
Recommended vehicle height adjustment range: Values ​​confirmed by the manufacturer.
Notes
The vehicle height data is reference measurement data for the development vehicle, so there may be differences due to individual differences in the vehicle and assembly conditions. (There may also be differences between the left and right sides, or the vehicle height may drop after a while due to settling after assembly.)
Using the vehicle height outside the recommended range may cause damage to the shock or vehicle, and may not comply with safety standards. Please note that the manufacturer will not take any responsibility for any damage that may occur in such cases.
Depending on the wheel size and offset, tire brand, and size, etc., interference may occur during driving even at the manufacturer’s standard position.
