Description

Ground height About 15mm down from the original
Configuration: MT car
* DLC (Diamond-Like Carbon) By electrodepositing carbon atoms on the chrome-plated part, a film with the same hardness as a diamond is formed.
Friction is reduced, and the piston rod moves smoothly even with minute movements, making the suspension work more effectively.
By adopting DLC * coating, which is also used in the field of motorsports, for the piston rod, friction is reduced, the suspension can move from a minute input, handling performance is improved, and supple ride quality is achieved. Especially when steering, linear responsiveness is achieved, and ideal line tracing is achieved.

Set includes.
① Shock absorber (FR RH) MS261-18001 1 Dust cover/bump stopper/lock nut
② Shock absorber (FR LH) MS262-18001 1 〃
③ Rod end nut (for Fr) 2 Upper mount x absorber (included with ①) M12 x P1.25
④ Nut A (for Fr) 6 Upper mount x body M8 x P1.25
⑤ Nut B (for Fr) 4 Knuckle x Absorber M14 x P1.5
⑥ Nut C (for Fr) 2 Stabil link x absorber M12 x P1.25
⑦ Shock absorber (RR) MS263-18001 2 Dust cover, bump stopper, top nut, collar
⑧ Rod end nut (for Rr) 2 Upper mount x pinton rod (included with ③) M10 x P1.25
⑨ Nut D (for Rr) 6 Lower arm x member, Lower arm x absorber , Lower arm x knuckle M12 x P1.25
⑩ Nut E (for Rr) 4 Upper mount x body M10 x P1.25
⑪ Nut F (for Rr) 2 Lower arm x stabilizer link M10 x P1.25
⑫ SST (hook wrench) 2
⑬ Installation and handling instructions (this document) 1 Please keep this manual in a safe place.
