JAOS BATTLEZ Damper VFS Ver.B (20) for Jimny JB74
¥68,000
Product number: B775513B
Please select per-product shipping when placing the order. This can be shipped via economy air shipping to most parts of Asia, the US, and Europe. However, the territories cannot be covered
with this shipping, we may request an additional shipping charge after the buyer places the order.
Description
Basic information
This high-performance damper is equipped with a fixed damping force and frequency-sensitive valve “Harmoflec® mechanism,” which alleviates the feeling of bumping up without changing the vehicle height.
Product contents | front damper, rear damper |
---|
Shock absorber
type | Low-pressure gas twin tube damper, Harmofleck® mechanism |
---|---|
Damping force adjustment | Fixed type |
damping force | Front: -20% on the rebound side, 31% on the compression side (0.3m / sec/stock ratio) Rear: 6% on the rebound side, -5% on the compression side (0.3m / sec/stock ratio) |
stroke | Front: +7mm, Rear: +13mm |
Body diameter | Front: 45.0Φ, Rear: 45.0Φ |
Piston diameter | Front: 30.0Φ, Rear: 30.0Φ |
Color | gray metallic |
Installation information
Installation method | Genuine replacement |
---|---|
Installation time | 0.5~1.0 hours |
Notes/Supplementary explanation
・Genuine coil spring: Can be installed
Packing size : H:200 × W:185 × D:700 mm
Packing weight : 9.1Kg
