Name: RSE Stroker Kit 4G63 EVO1-9 2.2 86.00
Availability: InStock

RSE Stroker Kit 4G63 EVO1-9 2.2 86.00

¥535,000

Product code: RA201A-MT01A

Please select per-product shipping when placing the order. This can be shipped via economy air shipping to most parts of Asia, the US, and Europe. However, the territories cannot be covered with this shipping, we may request an additional shipping charge after the buyer places the order.

Description

Bore diameter (mm)	86.0 (genuine +1.0)
Crank stroke (mm)	94.00 (genuine +6.0)
Displacement (cc)	2184.1
Fuel chamber volume (cc)	43.0
Crown Volume (cc)	-19.5
Deck clearance/height (mm)	-0.35
Compression Height (mm)	31.65 (genuine -3.35)
Center distance (mm)	150.00 (Original ±0.0)
Gasket bore diameter (mm)	86.5
Reference compression ratio 86.5-1.0	8.76
Reference compression ratio 86.5-1.2	8.63
Reference compression ratio 86.5-1.5	8.44
Reference compression ratio 86.5-1.8	8.27
