ATS Center Hub Method Metal Clutch Overhaul Set
¥94,000
Product code: R7A33-
Please select per-product shipping when placing the order. This can be shipped via economy air shipping to most parts of Asia, the US, and Europe. However, the territories cannot be covered with this shipping, we may request an additional shipping charge after the buyer places the order.
Description
Clutch inspection/measurement table/overhaul procedure (*Common to carbon and metal)
We will explain what to do if a clutch that has been used normally starts to slip or becomes difficult to disengage over a medium or long period of time. We measure the strain and wear of clutch parts and decide on the details of the overhaul work. We will illustrate and explain typical examples, but these may not match all clutches.
Conformity | Specification | Part Number | Price (Japanese Yen) | ||||
Clutch Type | Belleville washer | Clutch Cover | Crimping force | ||||
Compact
Type |
Spec1 | Small Diameter | Standard | 1300kg | R7A33- | 93 | 94,000 |
1600kg | 94 | ||||||
Spec1 for ZC31S | Small Diameter | Standard | 1000kg | R7A33- | 101 | ||
Spec1 for EG6,EK4/9,
DC2/8 |
Small Diameter #11 | Standard | 1300kg | R7A33- | 106 | ||
1600kg | 107 | ||||||
Spec1 for K20,DC5 | Small Diameter | Standard | 1300kg | R7A33- | 95 | ||
1600kg | 96 | ||||||
Spec1 for EG6,EK4/9,
DC2/8 |
Small Diameter #10 | Standard | 1300kg | R7A33- | 109 | ||
1600kg | 110 | ||||||
Spec2 | Small Diameter | Standard | 1600kg | R7A33- | 102 | ||
Reinforcement | 1600kg | 103 | |||||
2200kg | 99 | ||||||
Small Diameter | Standard | 1600kg | R7A33- | 104 | |||
Reinforcement | 1600kg | 105 | |||||
Spec2 for EG6,EK4/9, DC2/8 |
Small Diameter #11 | Standard | 1600kg | R7A33- | 108 | ||
Small Diameter #10 | 1600kg | 111 | |||||
Twin Clutch ※Except SW20,1ZZ,2ZZ |
Spec1 | – | – | – | R7A33- | 114 | 97,000 |
Spec2 | 116 | ||||||
Twin Clutch for ※SW20,1ZZ,2ZZ |
Spec1 | – | – | – | R7A33- | 115 | 97,000 |
Spec2 | 117 | ||||||
Tripple Clutch | Spec1 | – | – | – | R7A33- | 118 | 144,000 |
Spec2 | 119 |
Remarks
#10: Large hole diameter: Flat spring center hole diameter φ49.5mm (when using Honda genuine clutch bearing)
#11: Small hole diameter: Flat spring center hole diameter φ40mm (when using ATS specified clutch bearing)
