Product number 69005-14750
Old product number 69005-14750
Please select per-product shipping when placing the order. This can be shipped via economy air shipping to most parts of Asia, the US, and Europe. However, the territories cannot be covered with this shipping, we may request an additional shipping charge after the buyer place the order. 4.5% deduction when paying via Bank/WISE Payment
A80 Supra Lock Cylinder Set 69005-14750 (Old Part Number: 69005-14750) GR Heritage Parts Toyota Genuine CYLINDER ASSY, IGNITION SWITCH LOCK.
Product name
Lock cylinder set
Product number
69005-14750
Old product number
69005-14750
Model name
A80 Supra
Category
function
Item
Ignition / Door Lock Key & Key Cylinder
Quantity per unit
1
Conformity guide
North American specifications
(1996.07-1997.09)(Note) It can be installed on all specifications including Japanese specifications, but there will be changes. Please check the remarks column for details.
Product classification
Reprint parts (genuine)
Production period
-March 2025
* After the production period ends, it will be sold as long as it is in stock.
remarks
(Note) It is also possible to replace the Japanese specifications 69005-14680, -14740, -14760 and all other specifications. At that time, if the vehicle is currently lit with the ignition key lighting, it will not be lit. In addition, the key after replacement will not be stamped with the key number.
・ The key number will be a new number.
・ This set includes the following items. (3 keys, ignition switch lock cylinder ASSY, front door lock cylinder ASSY RH, front door lock cylinder ASSY LH, glove compartment door lock cylinder ASSY and luggage compartment door lock cylinder) ASSY)
・ The glove compartment door lock and luggage compartment door lock cylinder ASSY are currently being supplied separately.[When replacing with a North American specification vehicle]
-When replacing the luggage compartment door lock cylinder assembly, it may not be possible to connect the connector on some North American specification vehicles. In that case, replace it according to the following procedure.
1) Remove the cylinder side connector attached to the vehicle.
2) Remove the cylinder side connector of the reprinted product and replace it with the connector removed in 1).
3) Connect to the connector on the vehicle side.
If it is not connected to the connector on the vehicle side, security may sound when the door is unlocked.
