Description

Installation is easier than the old version! Just install the product by inserting it under the handle!
Equipped with automatic door lock, automatic door lock release, and sudden deceleration door lock release functions!
Lock and unlock timing can be switched!

[Compatible car models]
◎Yaris
Model: MXPA10/MXPA15/MXPH10/MXPH15/KSP210
Model year: January 2019 (R1) to December 2023 (R5)
*Operation has not been confirmed on cars that have undergone some improvements after January 2024 (R6).

◎Yaris Cross
Model: MXPJ10/MXPJ15/MXPB10/MXPB15
Year: August 2020 (R2) ~

◎GR Yaris
Model: MXPA12/GXPA16
Year: R2 September ~

*For manual transmission vehicles, please use only the settings to lock at vehicle speed and unlock at engine OFF.
*As this is an improved product, we are unable to confirm all grades. The product may not be usable due to some grades or third-party products.
Thank you for your understanding.

Message from the shop

Equipped with door lock/door unlock function
Lock and unlock timing can be changed!

〇There is a coupler at the end of all the wiring to be connected, so there is no difficult installation!
〇All wiring has couplers, so there is no need to cut the wiring, you can rest assured that there will be no damage or damage to the car’s wiring when removing it!
〇This product does not use electrotypes, etc., so there is no need to worry about wiring contact failure.
◯Children will not have to open the door in a hurry! Both the driver and passengers can ride safely and securely.

【Feature Description】
1.Door locks at approximately 10-15km/h or “D” shift (with switching function)
Have you ever had the experience of your child opening the door in a hurry even though it hasn’t stopped yet?
In addition, it can now prevent the door from being opened by a rash driver, the door being snatched by someone who is waiting at a traffic light, and children opening the door by mistake.
*In the case of gasoline-powered vehicles, it is designed to read the rotational speed and lock it. Therefore, the timing of locking will vary depending on how much you press the accelerator pedal, etc., but it will lock at approximately 10km/h to 15km/h.

*If you manually unlock the vehicle using the switch, it will not be automatically relocked until you shift the shift lever to “P” again. (If the unlock timing is set to “unlock when engine OFF”, automatic relocking will not occur)

2. After stopping, shift to P or turn off the engine to unlock the door (with switching function)
If you put the shift lever in P, the lock will be automatically released!
Allows passengers to get on and off smoothly.

Additionally, if you set the door to be unlocked with the engine off, you can rest assured that the door will remain locked even if the car is forced to stop and the door is suddenly opened, such as when driving in a tailspin manner.

3.Answer the backlight function (with ON/OFF switching)
When you turn off the engine and open the door for the first time (first time only), the small light will turn on for 10 seconds. Also, when you unlock your car (when you press the smart key once to unlock your car), the small light will turn on for 10 seconds.
*This answerback function may not be available depending on the vehicle model, grade, or whether it is a non-manufacturer product. This is not a product defect, so please be aware that this function may not be available before purchasing this product.

4.Automatic door unlocking in case of emergency
*This function is not available for gasoline vehicles. please note that
It operates during sudden deceleration of approximately 40 km/h or more. (e.g. from 60km/h to 20km/h or less) Release the lock to prepare for an emergency and avoid the risk of being trapped when escaping in an emergency.
*The time required to decelerate for normal operation varies depending on the vehicle model. Please note that it may not operate even when braking suddenly.
*This function cannot be turned off.

[Product contents]
・Vehicle speed linked door lock kit
・Installation instructions (common instructions for other car models) *There is no installation video. The installation is the same as Sienta, so please refer to that video.
・Plastic remover

【Notes】
-For car models and grades that have a back door open switch on the smart key, the back door may not open when you press the back door open button on the smart key.
In that case, after pressing the car unlock button on the smart key, press and hold the back door open button for about 3 seconds to open the back door.
(The back door opening operation from other than the smart key is the same as the genuine one.)

・If the rear monitor guide line is initialized If the connector under the handle is left disconnected for a certain period during installation, the rear monitor guide (the line in the rear camera image when reversing) will be initialized. There may be times when
In that case, turn off the engine, start it again, shift into reverse, turn the steering wheel to the left for 10 seconds, then turn it to the right for 10 seconds. The guideline will return to normal.

・If an error message appears on the information display after installation
Similarly, if the connector is disconnected for a certain period, errors such as clearance sonar may appear on the information display.
In that case, if you continue driving for several hundred meters, the loading settings for the function that caused the error display will be completed and the error display will disappear. If the error does not disappear even after driving, there is a possibility that the connector has a poor connection, so please reconnect the product’s connector firmly.

*Please note that some functions may not work due to compatibility issues specific to the model year, version, or vehicle body.
– If the device is manually locked or unlocked, the lock and unlock settings may not function as configured.
By turning off the engine and restarting it, it will be locked and unlocked according to the settings.

[Can be installed at the same time as other products! ] *Please check the product page for compatible car models.
・Products currently on sale by our company, “Door Open Hazard” and “Auto Brake Hold”, can also be installed at the same time.
Please attach it in series so that the coupler of all products to be used is inserted into the coupler pulled out from under the steering wheel of the car.

Function switching/gasoline type setting with the lever of the controller box
Functions can be switched using the lever on the controller box.
You can change the door lock/door unlock timing by setting the switch inside the product controller up and down. In addition, please set the car model to which the product is installed.
lever 1 UP: Door lock at speed (approximately 15km to 20km)
lever 1 Down: Door lock with D shift
lever 2 UP: P shift to unlock the door
lever 2 Down: Unlock the doors when the engine is off
lever 3 UP: Install the product and the engine of the model is “for hybrid vehicles”
lever 3 Down: If the product is installed and the engine is a “gasoline car”
*If the function of the product does not work, please change the lever position No. 3 once and check if it works.
