Description

Product Details

● 20-step damping force adjustment mechanism The
wide damping force adjustment range supports all situations from time attack on the circuit to street use.

● Adopting a dedicated upper mount
The combination of lightweight aluminum and dedicated reinforced rubber ensures a comfortable ride and good response. Both handling.

● Single tube and free piston
are used. Performance is more important than cost, and a single tube is used. The high-precision large-diameter piston moves smoothly, demonstrating stable damping force even when a heavy load is applied to a heavy vehicle.

● Full-length adjustment type vehicle height adjustment
Secures a sufficient stroke that can demonstrate performance even if the vehicle height is changed.

* Prices are for one vehicle (shock, spring, upper support assembled)
* Be sure to adjust the alignment after installing this product. The original performance will not be exhibited.

TOM’S Racing Suspension Kit Compatibility Table

Vehicle: Lexus GS F

Model: URL10

Grade: All grades

Year: H27.11 ～

Price: 384,000 yen

Single tube, free-piston 20-step damping force adjustment Damping force N extension side/compression side (0.3m / sec) F: 2600/950 R: 1950/800 (10th step) Spring rate (N / mm) F: 140 R: 120 * NAVI-AI-AVS does not work. * Lexus Safety System + malfunction may occur due to the decrease in vehicle height in vehicles equipped with Lexus Safety System +.

Vehicle: Lexus LC

Model: URZ100

Grade: LC500

Year: H29.3 ～

Price: 505,000 yen

Single tube, free-piston Front damping force 20-step adjustment Rear step-less adjustment F: 4341/984 R: 2628/708 (12th step) Spring rate (N / mm) F: 100 R: 60 * NAVI-AI-AVS is a function I will not. * Lexus Safety System + malfunction may occur due to the decrease in vehicle height in vehicles equipped with Lexus Safety System +. LC convertible installation is unconfirmed.

Vehicle: Lexus RC-F

Model: USC10

Grade: All grades

Year: H26.9～R1.2

Price: 384,000 yen

Single tube, free-piston 20-step damping force adjustment Damping force N extension side/compression side (0.3m / sec) F: 2850/1100 R: 2050/950 (10th step) Spring rate (N / mm) F: 160 R: 160 * NAVI-AI-AVS does not work.
